Abbildung ähnlich

Zubehör - RF-smart, Netzgerät 230V für 8 Zonen Wandfernbedienung (3,3V DC)

Artikelnummer: 872144 EAN: 4042943180544

13,95 EUR (exkl. MwSt.)

je 1

Mindestbestellmenge	1
Bestellschritt	1

Housing Material	Polycarbonate
Housing Color	White
Warranty (years)	5
badge_neu_en	false
badge_ausgelistet_en	false
Product state	Stock Item
Product Type	Electrical accessories
badge_sale_en	false
eShop visible	yes
Number of Channels	1
Length	48 mm
Width	27 mm
Height	21 mm
Rated Input Voltage	220-240 V/AC
Frequency	50 / 60 Hz
Power	3.0 W
Protection Class	Protection class II/protective insulation
IP Protection Class	IP 20
Life Time	50000 h
Switching Cycles	100000
Product weight	37 g
Output Voltage	3.3 V/DC
Output Current in mA	0-900 mA
Output Current max. in mA	900 mA
Output Current min. in mA	0 mA
Primary Connection	With free strand / conductor ends
Primary Cable Length	200 m
Secondary Connection	Plug-in system
Secondary Cable Length	170 m
Operating Mode	Constant voltage
Inrush Current max.	30 A / 100 µs
Power Factor	0.5
Max. units per MCB B10	23
Max. units per MCB B16	33
Max. units per MCB C10	36
Max. units per MCB C16	73
Working Temperature	-20 to 50 °C
Storage Temperature	-20 to 70 °C
Mounting Location	Inside
Functions	Short-circuit proof
