Housing Material	Aluminium
Housing Color, Color System	Deep black RAL 9005
Housing Color	Black
Lightcolor	Warm white (WW)
Color Temperature	2700 K
CRI (Ra)	90
Rated Luminous Flux	12000 lm
Warranty (years)	5
Inrush Current max.	6.1 A / 44 µs
Rated Angle of Reflection	90 Degree
badge_neu_en	false
badge_ausgelistet_en	false
Product state	Stock Item
Product Type	Surface-mounted ceiling light
badge_sale_en	false
eShop visible	yes
Dimmable	Yes
Control	DALI 2.0 / DT6
Height	80 mm
Diameter	1500 mm
Rated Input Voltage	198-264 V/AC
Frequency	50 / 60 Hz
Rated Input	99.0 W
Voltage range DC	176-276 V/DC
Protection Class	Protection class I/protective grounding
IP Protection Class	IP 40
IK Protection Class	IK05
Light Source	LED
Luminous Efficiency	121 lm/W
Light direction	Below
Colour Consistency	2 SDCM
Life Time L70 / B50	180000 h
Life Time L80 / B10	120000 h
Life Time L80 / B50	130000 h
Life Time L90 / B10	50000 h
Life Time L90 / B20	60000 h
Switching Cycles	100000 PCS
Product weight	11100 g
Through Wiring possible	Yes
Power Supply Unit Changeable	Yes by technician
Power Consumption	99 kWh/1000h
Max. units per MCB B10	16 PCS
Max. units per MCB B16	25 PCS
Max. units per MCB C10	16 PCS
Max. units per MCB C16	25 PCS
Working Temperature	-20 to 50 °C
Surface Temperature max.	80 °C
Storage Temperature	-40 to 80 °C
Mounting Type	Top mounting
Mounting Location	Inside
Mounting Area	Ceiling installation
UGR	19

Mindestbestellmenge	1
Bestellschritt	1

Deckenaufbauleuchte - Lautaro 1500/80 Prisma, 99 W, DALI, 2700 K, Schwarz
